Description
Engineering drawings present a very abstract image of the components or devices with precise specifications. Using geometric and graphical features such as lines and symbols, as well as alphanumeric characters such as digits and letters, a three-dimensional object is described in two dimensions.
Reading and understanding engineering drawings is a fundamental element in the development of professional competence in all engineering disciplines.
